Pin (3-4) of JBAT (8-pin): RTC Reset
Pin (3-4) of JBAT → RTC Reset
Pin1
2
3
4
3-4 Open: Normal(Default);
;
3-4 Closed:RTC Reset.
2
4
Pin1
3
Pin (5-6) of JBAT (8-pin): Flash Override Slect
Pin (5-6) of JBAT → Flash Override
Pin1
2
3
4
2 4
Pin1
3
5-6 Open:Enable Security Measures
in the Flash Descriptor(Default);
5-6 Closed: Disable Security Measures
in the Flash Descriptor(Override).
5
6
6
5
JBAT
JBAT
