Intel Denverton Series User Manual

1
Chapter 1
Introduction of the Motherboard
1-1 Feature of Motherboard
 Intel
®
Denverton series SoC Processor
 4*288-pin U-DIMM/R-DIMM slots support 4* DDR4 2133/2400MHz ECC SDRAM,
up to 256GB memory
 Support 2 * Intel i210AT GbE & 4 * 10GbE SPF+ ports
 Support 4 * SATA III & M.2 (M key, SATA interface, 2242/2260/2280) storage
 1 * full size Mini-PCIe slot & 1 * PCIe x8 (use PCIe x16 slot) for riser card
expansion
 3 * External USB3.0 & 2 * Internal USB2.0
 1 * Internal VGA pin header
 Support Intel AES NI and on-board TPM to secure customers’ data
 Support Smart FAN function
 Compliance with ErP standard
 Support Watchdog function
 Solution for Surveillance, IoT & Networking Appliance
