1-2 Specification
Spec Description
Design
 Mini-ITX form factor ;
 PCB size: 17.0 x 17.0 cm
Embedded
CPU
 Intel
®
Denverton series SoC Processor
* for detailed CPU support information please visit our website
Memory Slot
 4* 288-pin U-DIMM/R-DIMM DDR4 slot
 Support 4* DDR4 2133/2400 MHz U-DIMM/R-DIMM SDRAM up to
256GB
 Support dual channel function (*
refer to P-14 for installation guide
)
Expansion Slot
 1* Full-size Mini-PCIE slot
(MPE)
 1* PCIE x8 slot
(PCIEX8)
Storage
 4* SATAIII 6Gb/s port
(SATA1/2/3/4)
 1* M.2 Slot (Socket 3, M-key, support type-2242/2260/2280 SSD)
Networking
 Integrated with 2* Intel I210AT PCI-E Gigabit LAN chips
 Support 2 * RJ-45 GbE ports & 4 * SPF+ 10GbE ports
BIOS
 AMI Flash ROM
Rear Panel I/O
 3* USB 3.0 port
 2* RJ-45 LAN port
 4* SPF+ port
Internal I/O
 1*24-pin main power connector
 1*8-pin 12V power connector
 1*CPUFAN connector & 1* SYSFAN connector
 1*Front panel header
 1* 9-Pin USB 2.0/1.1 header for 2* USB 2.0/1.1 ports
 1* GPIO header
 1* Front VGA port header (
Max. Resolution
: 1920x1200@60Hz)
 2* RS232 serial port header (
COM1/2
)
