16
GPIO (10-pin): GPIO Port Header
Pin 1
2
GPIO_
D
7
GPIO_
D
5
GPIO_
D
3
GPIO_
D
6
GPIO_
D
4
GPIO_
D
2
VCC
GPIO_D0
GND
GPIO_D1
FP_VGA (15-pin): VGA Header
GREEN
Pin1
Pin
2
RED
NC
GND
GND
GND
DCC-DAT
A
VSYNC
BLUE
VCC_
+5V
GND
GND
NC
HSYNC
DCC_CLK
GPIO
FP_VGA
