28
Legacy Console Redirection
Legacy Console Redirection Settings
Press [Enter] to make settings for the following items:
Redirection COM Port
Use this item to select a COM port to display redirection of Legacy OS and
Legacy OPROM Messages.
The default setting is: [COM1].
Resolution
On Legacy OS, the Number of Rows and Columns supported redirection.
The optional settings: [80x24]; [80x25].
Redirection After BIOS POST
The optional settings are: [Always Enable]; [BootLoader].
Whet [Bootloader] is selected, then Lagacy Console Redirection is disabled
before booting to legacy OS. When [Always Enable] is selected, then Legacy
Console is enabled for legacy OS. Default setting for this option is set to [Always
Enable].
Serial Port for Out-of-Band Management/
Windows Emergency Management Services (EMS)
Console Redirection
The optional settings: [Disabled]; [Enabled]. When set as [Enabled], the following
sub-items shall appear:
Console Redirection Settings
The settings specify how the host computer and the remote computer (which the
user is using) will exchange data. Both computers should have the same or
compatible settings.
Press [Enter] to make settings for the following items:
Out-of-Band Mgmt Port
The optional setting is: [COM1].
Terminal Type
The optional settings: [VT100]; [VT100+]; [VT-UTF8]; [ANSI].
