1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of the board.
Table 1. Feature Summary
Form Factor
MicroATX (9.60 inches by 9.60 inches [243.84 millimeters by
243.84 millimeters])
Processor
• Intel
®
Core™ i7, Intel
®
Core™ i5, Intel
®
Core™ i3, and Intel
®
Pentium
®
processors in an LGA1156 socket:
― Integrated graphics processing (processors with Intel
®
Graphics
Technology)
― External graphics interface controller
― Integrated memory controller
Chipset
Intel
®
H55 Express Chipset consisting of the Intel
®
H55 Platform Controller
Hub (PCH)
Memory
• Four 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR3 1333 MHz and DDR3 1066 MHz DIMMs
• Support for 1 Gb and 2 Gb memory technology
• Support for up to 16 GB of system memory with four DIMMs using 2 Gb
memory technology
• Support for non-ECC memory
Graphics
• Integrated graphics support for processors with Intel Graphics Technology:
― VGA
― HDMI
― DVI-D
• Discrete graphics support for PCI Express 2.0 x16 add-in graphics card
Audio Intel
®
High Definition Audio via the Realtek* ALC888S audio codec and the HDMI
interface
Peripheral
Interfaces
• Twelve USB 2.0 ports:
― Six ports are implemented with stacked back panel connectors
― Six front panel ports are implemented with three dual-port internal
headers; one header supports an Intel Z-U130 USB Solid-State Drive (or
compatible device)
• Six internal Serial ATA (SATA) 3.0 Gb/s ports:
― Two ports compatible with eSATA dongles
• One serial port header
• One parallel port header
• One back panel PS/2 connector
BIOS
• Intel
®
BIOS resident in the SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
continued
