Intel Desktop Board DH67CL Product Guide
30
Installing and Removing the Desktop Board
CAUTION
Only qualified technical personnel should perform this procedure. Disconnect the
computer from its power source before performing the procedures described here.
Failure to disconnect the power before you open the computer can result in personal
injury or equipment damage.
Refer to your chassis manual for instructions on installing and removing the Desktop
Board.
Figure 5 shows the location of the mounting s
crew holes for Intel Desktop Board
DH67CL.
Figure 5. Intel Desktop Board DH67CL Mounting Screw Hole Locations

Intel DH67CL Specifications

General

Form Factor	ATX
Chipset	Intel H67
Socket	LGA 1155
Memory Slots	4
Max Memory	32 GB
Memory Type	DDR3
PCI Express x16	1
PCIe 2.0 x1 Slots	2
PCI Slots	2
SATA 3Gb/s	3
SATA 6Gb/s	2
USB 3.0 Ports	2
LAN	Gigabit Ethernet
Video Outputs	HDMI, DVI
Integrated Graphics	Yes
