Intel DH87RL User Manual

Technical Reference
45
Table 18. Front Panel USB 3.0 Connector
Pin Signal Name Description
1 Vbus Power
2 IntA_P1_SSRX− USB 3 ICC Port1 SuperSpeed Rx−
3 IntA_P1_SSRX+ USB 3 ICC Port1 SuperSpeed Rx+
4 GND Ground
5 IntA_P1_SSTX− USB 3 ICC Port1 SuperSpeed Tx−
6 IntA_P1_SSTX+ USB 3 ICC Port1 SuperSpeed Tx+
7 GND Ground
8 IntA_P1_D− USB 3 ICC Port1 D− (USB 2 Signal D−)
9 IntA_P1_D+ USB 3 ICC Port1 D+ (USB 2 Signal D+)
10 ID Over Current Protection
11 IntA_P2_D+ USB 3 ICC Port2 D+ (USB 2 Signal D+)
12 IntA_P2_D− USB 3 ICC Port2 D− (USB 2 Signal D−)
13 GND Ground
14 IntA_P2_SSTX+ USB 3 ICC Port2 SuperSpeed Tx+
15 IntA_P2_SSTX− USB 3 ICC Port2 SuperSpeed Tx−
16 GND Ground
17 IntA_P2_SSRX+ USB 3 ICC Port2 SuperSpeed Rx+
18 IntA_P2_SSRX− USB 3 ICC Port2 SuperSpeed Rx+
19 Vbus Power
20 Key (no pin) No connect
Table 19. SATA Connectors
Pin Signal Name
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
Table 20. S/PDIF Header
Pin Signal Name
1 Ground
2 S/PDIF out
3 Key (no pin)
4 +5 V DC

Intel DH87RL Specifications

General

Form Factor	Micro ATX
Chipset	Intel H87
Socket	LGA 1150
Memory Slots	4
Maximum Memory	32 GB
Memory Type	DDR3
PCI Express x16	1
SATA Ports	6
Video Output	HDMI, DVI-D, VGA
Audio Codec	Realtek ALC892
RAID Support	RAID 0, 1, 5, 10
PCI Express x1	2
USB Ports	8 USB 2.0
LAN	Intel 82579V Gigabit LAN
