Intel Desktop Board DH87RL Technical Product Specification

Table 21. Processor, Front, and Rear Chassis

(4-Pin) Fan Headers

Pin Signal Name

1 Ground

(Note)

2 +12 V

3 FAN_TACH

4 FAN_CONTROL

Note: These fan headers use Pulse Width Modulation control for fan speed.

Table 22. Front Panel CIR Receiver (Input) Header

Pin Signal Name

1 Ground

2 LED

3 NC

4 Learn-in

5 5 V standby

6 VCC

7 Key (no pin)

8 CIR Input

Table 23. Chassis Intrusion Header

Pin Signal Name

1 Intruder#

2 Ground

Table 24. TPM Header

Pin Signal Name Pin Signal Name

1 PCICLK 2 GND

3 FRAME 4 Key (no pin)

5 PCIRST 6 N/C

7 LAD3 8 LAD2

9 VCC3 10 LAD1

11 LAD0 12 GND

13 N/C 14 N/C

15 3VSB 16 SERIRQ

17 GND 18 CLKRUN

19 PWRDWN 20 N/C
