Desktop Board Features
13
Table 2. Intel Desktop Board DP43BFL Components
Label Description
A PCI bus connector
B S/PDIF header
C PCI bus connector
D PCI bus connector
E PCI bus connector
F Speaker
G PCI Express x1 connector
H PCI Express x16 connector
I PCI Express x1 connector
J Battery
K Back panel connectors
L 12 V processor core voltage connector (2 x 2 pin)
M Rear chassis fan header
N Processor socket
O Processor fan header
P DDR3 Channel A DIMM sockets
Q DDR3 Channel B DIMM sockets
R BIOS configuration jumper block
S Front panel header
T Alternate front panel power LED header
U Main power connector (2 x 12 pin)
V Parallel ATA connector
W Front chassis fan header
X Standby power LED
Y Auxiliary chassis fan header
Z Serial ATA connectors
AA Front panel USB 2.0 headers
BB Intel HD Audio Link header
CC Chassis intrusion header
DD Serial port header
EE Front panel audio header
