Desktop Board Features
17
Go to the following locations for more information about:
• Audio drivers and utilities http://www.intel.com/support/motherboards/desktop
• Location of the onboard audio headers, Figure 22 on page 45
• The location and description of the
back panel audio connectors, Figure 23 on
page 50
Table 3 lists the supported functions for the front panel and back panel audio jacks.
Table 3. Back Panel and Front Panel Audio Jack Retasking Support
Jack Mic Headphones
Front
Speaker
Line
In
Side
Surround
Rear
Surround
Center/
Subwoofer
Front Panel
Green Default Control Panel
Pink Default
Back Panel
Blue Control Panel Default Control Panel
Green Control Panel Default
Pink Default
Black Default
Orange Default
Legacy Input/Output (I/O) Controller
The legacy I/O controller provides the following:
• One serial port interface via an onboard header
• Two PS/2 ports for keyboard and mouse support
• Serial IRQ interface compatible with serialized IRQ support for PCI systems
• Intelligent power management, including a programmable wake up event interface
• PCI power management support
