Intel DP67BG User Manual

Desktop Board Features
13
Table 2. Intel Desktop Board DP67BG Components
Label Description
A PCI Express 2.0 x1 connector
B PCI bus connector
C PCI Express 2.0 x16 connector (x8 electrical; x16 compatible)
D Front panel audio header
E PCI bus connector
F PCI Express 2.0 x1 connector
G PCI Express 2.0 x16 connector
H Rear chassis fan header
I PCI Express 2.0 x1 connector
J Back panel connectors
K 12 V processor core voltage connector (2 x 4 pin)
L Processor socket
M Processor fan header
N DIMM 3 socket
O DIMM 1 socket
P DIMM 4 socket
Q DIMM 2 socket
R Alternate front panel power LED header
S Main power connector (2 x 12 pin)
T POST code LED display
U Onboard reset button
V Onboard power button
W Speaker
X Front chassis fan header
Y Battery
Z Serial ATA (SATA) connectors
AA BIOS configuration jumper block
BB Back panel CIR transmitter (output) header
CC Front panel CIR receiver (input) header
DD USB 2.0 headers
EE Chassis intrusion header
FF IEEE 1394a header
GG Front panel header
HH Diagnostic LEDs
II S/PDIF header
JJ Auxiliary chassis fan header

Intel DP67BG Specifications

General

Form Factor	ATX
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	4
Maximum Memory	32GB
PCI Express x16	2
PCI Express x1	3
SATA 3Gb/s	4
SATA 6Gb/s	2
USB 2.0 Ports	12
USB 3.0 Ports	2
Audio Chipset	Realtek ALC892
Audio Channels	8
LAN Chipset	Intel 82579V
Max LAN Speed	10/100/1000Mbps
PS/2	1
eSATA	1
RAID Support	Yes
Chipset	Intel P67 Express
Memory Standard	DDR3 1333
S/PDIF Out	1
