Intel Desktop Board DP67BG Product Guide
34
3.
Rotate t
he socket lever to lift the load pl
ate away from the socket (
Figu
re 10, A).
Make sure that th
e load plate is in the fully open
position (
Figure 10, B) while being
careful not to damage adjacent co
mponen
ts. Do no
t touch the socket contacts.
Figure 10. Lift the Lo
ad Plate
33
35
