Intel DQ67OW User Manual

Product Description
19
1.8 USB
The board supports up to 14 USB 2.0 ports. The Intel Q67 Express Chipset provides
the USB controller for the 2.0 ports. The port arrangement is as follows:
• Six USB 2.0 ports are implemented with stacked back panel connectors
• Eight USB 2.0 front panel ports implemented through four internal headers
All 14 USB ports are high-speed, full-speed, and low-speed capable.
NOTES
Computer systems that have an unshielded cable attached to a USB port may not
meet FCC Class B requirements, even if no device is attached to the cable. Use a
shielded cable that meets the requirements for full-speed devices.
For information about Refer to
The location of the USB connectors on the back panel Figure 9, page 44
The location of the front panel USB headers Figure 10, page 45

Intel DQ67OW Specifications

General

Form Factor	Micro ATX
Chipset	Intel Q67
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	4
Max Memory	32 GB
PCI Express x16	1
PCI Express x1	2
SATA 6Gb/s	2
SATA 3Gb/s	4
Ethernet	Gigabit Ethernet
Audio	7.1 channel
USB Ports	14 (4 rear, 6 front, 4 via headers)
