Intel Desktop Board DQ67OW Technical Product Specification
54
2.2.2.4.2 Reset Switch Header
Pins 5 and 7 can be connected to a momentary single pole, single throw (SPST) type
switch that is normally open. When the switch is closed, the board resets and runs the
POST.
2.2.2.4.3 Power LED Header
Pins 2 and 4 can be connected to a one- or two-color LED. Table 25 shows the default
states for thi
s LED. More options are available through BIOS setup.
Table 25. States for a One-Color Power LED
LED State Description
Off Power off/sleeping
Steady Lit Running
Blink Standby
2.2.2.4.4 Power Switch Header
Pins 6 and 8 can be connected to a front panel momentary-contact power switch. The
switch must pull the SW_ON# pin to ground for at least 50 ms to signal the power
supply to switch on or off. (The time requirement is due to internal debounce circuitry
on the board.) At least two seconds must pass before the power supply will recognize
another on/off signal.
2.2.2.5 Alternate Front Panel Power LED Header
Pins 1 and 3 of this header duplicate the signals on pins 2 and 4 of the front panel
header.
Table 26. Alternate Front Panel Power LED Header
Pin Signal Name In/Out Description
1 FP_LED+ Out FP_LED+
2 Not connected
3 FP_LED− Out FP_LED−

Intel DQ67OW Specifications

General

Form Factor	Micro ATX
Chipset	Intel Q67
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	4
Max Memory	32 GB
PCI Express x16	1
PCI Express x1	2
SATA 6Gb/s	2
SATA 3Gb/s	4
Ethernet	Gigabit Ethernet
Audio	7.1 channel
USB Ports	14 (4 rear, 6 front, 4 via headers)
