Technical Reference
49
Table 18. Processor (4-Pin) Fan Header
Pin Signal
Name
1 Ground
2 +12
V
3 FAN_TACH
4 FAN_CONTROL
Table 19. Front and Rear Chassis Fan Headers
Pin 4-Wire
Support
Pin 3-Wire
Support
1 Ground
3 Ground
2 +12
V
2 FAN_POWER
3 FAN_TACH
1 FAN_TACH
4 FAN_CONTROL
N/A
N/A
Table 20.
Intel FCFH Header
Pin Description
1
Ground
2 FCFH#
48
