Intel Desktop Board DQ67OW Technical Product Specification
50
Table 21. Diskette Drive Connector
Pin Signal Name
1 Ground
2 Density Select
3 Ground
4 Reserved
5 Ground
6 Reserved
7 Ground
8 Index
9 Ground
10 Motor Enable Drive A
11 Ground
12 Drive Select B
13 Ground
14 Drive Select A
15 Ground
16 Motor Enable Drive B
17 Ground
18 Direction Select
19 Ground
20 Head Step
21 Ground
22 Write Data
23 Ground
24 Floppy Write Enable
25 Ground
26 Track 00
27 Ground
28 Write Protect
29 Ground
30 Read Data
31 Ground
32 Head Select
33 Ground
34 Disk Change

Intel DQ67OW Specifications

General

Form Factor	Micro ATX
Chipset	Intel Q67
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	4
Max Memory	32 GB
PCI Express x16	1
PCI Express x1	2
SATA 6Gb/s	2
SATA 3Gb/s	4
Ethernet	Gigabit Ethernet
Audio	7.1 channel
USB Ports	14 (4 rear, 6 front, 4 via headers)
