Intel Desktop Board DQ67OW Technical Product Specification
46
Table 9. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10 Descript
ion
A Conventional PCI bus add-in card connector
B Front panel audio header
C PCI Express x4 bus add-in card connector
D Internal mono speaker header
E PCI Express x1 bus add-in card connector
F PCI Express x16 bus add-in card connector
G 12 V internal power connector (ATX12V)
H Processor fan header
I Serial port header
J Chassis intrusion header
K Front chassis fan header
L Diskette drive connector
M Main power connector (2 x 12)
N Alternate front panel power LED header
O Front panel header
P SATA connectors
Q Intel MEBX Reset header
R Front panel USB header
S Intel FCFH header
T Front panel USB header
U Front panel USB header
V Front panel USB header
W S/PDIF header
X Rear chassis fan header

Intel DQ67OW Specifications

General

Form Factor	Micro ATX
Chipset	Intel Q67
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	4
Max Memory	32 GB
PCI Express x16	1
PCI Express x1	2
SATA 6Gb/s	2
SATA 3Gb/s	4
Ethernet	Gigabit Ethernet
Audio	7.1 channel
USB Ports	14 (4 rear, 6 front, 4 via headers)
