Desktop Board Features
13
Table 2. Intel Desktop Board DX58OG Components
Label Description
A Front panel audio header
B PCI Express 1.1 x1 connector
C PCI Express 1.1 x1 connector
D PCI bus connector (x8 electrical)
E PCI Express 2.0 x16 connector
F PCI Express 1.1 x1 connector
G PCI Express 2.0 x16 connector
H Rear chassis fan header
I Back panel connectors
J Processor fan header
K 12 V processor core voltage connector (2 x 4 pin)
L Processor socket
M DIMM 4 socket
N DIMM 1 socket
O DIMM 5 socket
P DIMM 2 socket
Q DIMM 6 socket
R DIMM 3 socket
S Main power connector (2 x 12 pin)
T Front chassis fan header
U Serial ATA connectors (3 Gb/s)
V Serial ATA connectors (6 Gb/s)
W Chassis intrusion header
X Speaker
Y USB 2.0 headers
Z Front panel CIR receiver (input) header
AA Back panel CIR transmitter (output) header
BB BIOS configuration jumper block
CC Front panel header
DD Alternate front panel power LED header
EE POST code LED display
FF IEEE 1394a header
GG Battery
HH Reset button
II Power button
JJ Auxiliary chassis fan header
KK Diagnostic/status LEDs
