Intel Desktop Board DX58OG Product Guide
54
Setting the BIOS Configuration Jumper
NOTE
Always turn off the power to the computer before moving the jumper. Moving the
jumper with the power on may result in unreliable computer operation.
Figure 27 shows the location of the Desktop Board’s BIOS confi
gurati
on jumper block.
Figure 27. Location of the BIOS Configuration Jumper Block
The three-pin BIOS jumper block enables all board configurations to be done in the
BIOS Setup program. Table 13 shows the jumper settings for
the BIOS Setup
program modes.
