9
1 Desktop Board Features
This chapter briefly describes the features of Intel
®
Desktop Board DX58OG. Table 1
summarizes the major features of the Desktop Board.
Table 1. Feature Summary
Form Factor
ATX (304.80 millimeters [12.00 inches] x 243.84 millimeters
[9.60 inches])
Processor Support for an Intel
®
processor in the LGA1366 package
Main Memory
• Six 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM)
sockets arranged in three channels
• Support for DDR3 1600+, DDR3 1333 MHz, DDR3 1066 MHz, and
DDR3 800 MHz DIMMs. Speeds over 1600 MHz are supported via
XMP profiles
• Support for ECC and non-ECC memory
• Support for up to 24 GB of system memory
Chipset Intel
®
X58 Express Chipset consisting of:
• Intel X58 Express Chipset I/O Hub (IOH)
• Intel
®
I/O Controller Hub (ICH10R) supporting Intel
®
Matrix Storage
Technology
Graphics Support for multiple PCI Express* graphics cards including linked cards
using Nvidia* SLI* technology and ATI CrossFireX* technology
Audio
• Independent multi-streaming 6-channel (5.1) audio and 2-channel
audio subsystem, featuring:
― Intel
®
High Definition Audio interface
― RealTek* ALC892 codec
• HD Audio front panel header
Expansion
Capabilities
• Two PCI Express 2.0 x16 ports
• Three PCI Express 1.1 x1 ports
• One PCI* bus connector
Legacy I/O Support Legacy I/O Controller that provides Consumer Infrared (CIR) support
Peripheral
Interfaces
• Up to 12 USB 2.0 ports:
― Six ports routed to the back panel
― Six ports routed to three USB headers
• Up to two IEEE 1394a ports:
― One port routed to the back panel
― One port routed to an IEEE 1394a header
• Two Serial ATA (SATA) channels (6.0 Gb/s) via a discrete controller
• Six Serial ATA (SATA) channels (3.0 Gb/s) via ICH10R
RAID
• Intel
®
Matrix Storage Technology for Serial ATA
continued
