Intel DX58OG User Manual

Intel Desktop Board DX58OG Product Guide
36
7. Close the load plate (Figure 13, A, B). As the load plate is closed, the socket cover
(Figure 13, C) will pop off as shown. After the load plate is closed, engage the
socket lever (Figure 13, D) under the latch.
Figure 13. Close the Load Plate
8. Pickup the socket cover (Figure 13, C) and remove it from the board.
NOTE
Do not discard the socket cover; save it for possible future use. Always replace
the socket cover if you remove the processor from the socket.

Intel DX58OG Specifications

General

Brand	Intel
Model	DX58OG
Category	Motherboard
Language	English
