Intel Desktop Board DZ68BC Product Guide
10
Table 1. Feature Summary (continued)
Peripheral
Interfaces
USB Support:
• Four USB 3.0 ports:
― Two ports implemented with stacked back panel connectors
(blue)
― Two ports via an internal dual-port connector (blue)
• Fourteen USB 2.0 ports:
― Six ports implemented with stacked back panel connectors
(black)
― Eight front panel ports implemented with four dual-port internal
headers (black)
Serial ATA (SATA) Support:
• Four SATA 6.0 Gb/s ports:
― Two ports from the Intel Z68 PCH (dark blue)
― Two ports from an onboard Marvell controller (light blue)
• Four SATA 3.0 Gb/s ports (black)
• One external SATA (eSATA) 6.0 Gb/s port on the back panel from
an onboard Marvell controller (red)
IEEE 1394a Support:
• One port routed to the back panel
• One port routed to the IEEE 1394a header
RAID
Intel
®
Rapid Storage Technology (Intel
®
RST) version 10.6
LAN Support Intel 82579V Gigabit (10/100/1000 Mb/s) Ethernet LAN controller
including an RJ-45 back panel connector with integrated status LEDs
BIOS
• Intel
®
Platform Innovation Framework for extensible firmware
interface
• 32 Mb symmetrical flash memory device
• Support for SMBIOS
• Intel
®
Express BIOS Update
Power Management
• Support for Advanced Configuration and Power Interface (ACPI)
• Suspend to RAM (STR)
• Wake on USB, PCI, PCI Express, LAN, CIR, serial port, and front
panel
• ENERGY STAR* capable
Hardware and
Thermal
Management
Hardware and thermal management based on:
• Nuvoton W83677HG-I legacy I/O controller
• Four fan sensing inputs to monitor fan activity
• Voltage sensing to detect out of range values
