Intel Desktop Board DZ68BC Product Guide
54
USB 3.0 Connector
Figure 24, K shows the location of the USB 3.0 connector. Table 16 shows the pin
assignments and signal names for the USB 3.0 connector. The USB 3.0 connector can
be used to connect two USB devices.
Table 16. USB 3.0 Connector
Pin Signal Name Pin Signal Name
10 ID 11 IntA_P2_D+
9 IntA_P1_D+ 12 IntA_P2_D−
8 IntA_P1_D− 13 Ground
7 Ground 14 IntA_P2_SSTX+
6 IntA_P1_SSTX+ 15 IntA_P2_SSTX−
5 IntA_P1_SSTX− 16 Ground
4 Ground 17 IntA_P2_SSRX+
3 IntA_P1_SSRX+ 18 IntA_P2_SSRX−
2 IntA_P1_SSRX− 19 Vbus
1 Vbus 20 Key (no pin)
