Desktop Board Features
13
Table 2. Intel Desktop Board DZ68BC Components
Label Description
A PCI bus connector
B PCI bus connector
C S/PDIF header
D PCI Express 2.0 x16 connector (x8 electrical; x16 compatible)
E Speaker
F PCI Express 2.0 x1 connector
G PCI bus connector
H PCI Express 2.0 x16 connector
I Rear chassis fan header
J PCI Express 2.0 x1 connector
K Back panel connectors
L 12 V processor core voltage connector (2 x 4 pin)
M Processor socket
N Processor fan header
O DIMM 3 socket
P DIMM 1 socket
Q DIMM 4 socket
R DIMM 2 socket
S Front panel CIR receiver (input) header
T Back panel CIR transmitter (output) header
U Main power connector (2 x 12 pin)
V Standby power indicator LED
W Onboard reset button
X Onboard power button
Y Front panel header
Z Front chassis fan header
AA Alternate front panel power LED header
BB Intel Z68 PCH
CC Battery
DD Two 6.0 Gb/s SATA ports (Marvell controller)
EE Two 6.0 Gb/s SATA ports (Intel Z68 PCH)
FF Four 3.0 Gb/s SATA ports (Intel Z68 PCH)
GG Serial port header
HH USB 2.0 headers
II BIOS configuration jumper block
JJ POST code LED display
KK Chassis intrusion header
