UAS and Safety Check
Inspection Payload ZS50*
The UAS and safety check must be performed once a day before the rst ight, and any time it may be necessary (e.g. after
an incident like a hard landing). If you notice anything unusual, please contact support through your dealer, if you purchased
through a dealer; or support at Intel, if you purchased directly from Intel. You must follow these steps to complete a close UAS
and safety check:
Important settings on both cameras can be controlled via the Intel Cockpit Controller:
To access the camera options, navigate to ‘Camera Option’ on the Status Display:
To access the camera options, navigate to ‘Camera Option’ on the Status Display:
Additional cameras may be available. Please refer to the main manual (http://intel.com/Falconmanual) if your camera is not described here.
B2 Position Activated Camera R2 Function
1 (LED o) Panasonic* RGB
Camera
Zoom In/Out Please note that shooting
parameters like shutter speed,
aperture and ISO need to be set
directly on the camera before
take-o.
2 (LED on/Blue) FLIR Up - Trigger at eld correction
Down - Cycle through color
palette
Please note that preview
parameters like isotherms
and ACG need to be set via
conguration le on the FLIR SD
card before take-o.
Record/Stop Starts and stops a video recording
Dial 2 See previous table for details
Review Reviews images stored on the SD card
Adjust Horizon Adjusts the horizon (roll angle) while ying
Roll Comp. ON/OFF Sets the gimbal to stop compensating roll movements
Switch Camera Switches the live image preview between the two cameras
Adjust Horizon Adjusts the horizon (roll angle) while ying
Roll Comp. ON/OFF Sets the gimbal to stop compensating roll movements
1 Is the transport case free of
visible damage?
If there is new visible damage from the last transport, take special care
during the check of the complete UAS.
2 Is the UAS free of visible
damage?
If there is visible damage, contact your supplier.
3 Are all the propellers in good
condition?
Replace propellers if there are any nicks, cracks, breaks or other damage.
Shooting parameters need to be set directly on the camera before take-o.
oPERATInG ThE UAS
