Intel H110 User Manual

6
Jumper
Jumper
Name
Description
JCOMP1
COM1 Port Pin9 Function Select
4-pin Block
JCOMP2
COM2 Port Pin9 Function Select
4-pin Block
JCOMP3
COM3 Port Pin9 Function Select
4-pin Block
JBAT
Clear CMOS RAM Settings
2-pin Block
JP1
Pin(1-2): Case Open Message Display Function
Pin(3-4): ATX Mode / AT Mode Select
Pin(5&6)：LAN1 Activity LED Header
Pin(7&8)：LAN2 Activity LED Header
8-pin Block
JP2
ME_Features Select
2-pin Block
MPE_PWR
MPE1 Slot MPE_PWR VCC 3.3V/3.3VSB Select
3-pin Block
EDP_BKPWR
EDP Backlight VCC 3 V/5V/12V Select
4-pin Block
EDP_LCDPWR
EDP Panel Backlight VCC 3 V/5V/12V Select
4-pin Block
Connectors
Connector
Name
ATXPWR1
24-Pin ATX Main Power Connector
ATX12V1
4-Pin 12V Power Connector
COM1_COM2
Serial Port COM Connector X2
COM3_VGA
Top: Serial Port COM Connector X1
Bottom: VGA Port Connector
HDMI1
HDMI Port Connector
UL1/UL2
Top:RJ-45 LAN Connector X2
Middle & Bottom: USB 3.0 Port Connector X4
AUDIO1
Top: Line-in Connector
Middle: Line-out Connector
Bottom: MIC Connector
SATA1/2
SATAIII Connector
CPUFAN1, SYSFAN1
FAN Connector X2
EDP1
EDP Connector

Intel H110 Specifications

General

Socket	LGA 1151
Memory Type	DDR4
Max Memory	32 GB
Memory Slots	2
PCIe 3.0 x16 Slots	1
PCI Express Lanes	6
RAID Support	No
Chipset	Intel H110
SATA Ports	4
Form Factor	ATX, Micro-ATX, Mini-ITX
Memory Speed	2133 MHz
USB 3.0 Ports	4
USB 2.0 Ports	6
Memory Channels	2
