20
(3) PS2KBMS1 (6-pin): PS/2 Keyboard & Mouse Header
(2.54 pitch)
GND
KB_CLK
KB_DATA
Pin1
MS_DATA
VCC
MS_CLK
(4) SMBUS (5-Pin): SMBUS Header
(2.54 pitch)
SMBUS_CLK
VCC3
Pin1
SMBUS_DATA
GND
SMBUS_ALERT
