Intel H61 User Manual

13
(3) GPIO_CON (10-pin): GPIO Header
9
GPIO
GND
GPIO GPIO GPIO
GPIO
GPIO
2
Pin 1
10
VCC
GPIO
GPIO
(4) PARALLEL (25-pin): Parallel Port Header
Pin 1
Parallel Port Header
Pin 14
Pin NO.
Pin Definition Pin NO. Pin Definition
Pin 1
STB-
Pin 14
AFD-
Pin 2
PRD0
Pin 15
ERR-
Pin 3
PRD1
Pin 16
INIT-
Pin 4
PRD2
Pin 17
SLIN-
Pin 5
PRD3
Pin 18
GND
Pin 6
PRD4
Pin 19
GND
Pin 7
PRD5
Pin 20
GND
Pin 8
PRD6
Pin 21
GND
Pin 9 PRD7 Pin 22 GND
Pin 10 ACK- Pin 23 GND
Pin 11 BUSY Pin 24 GND
Pin 12 PE Pin 25 GND
Pin 13 SLCT

Intel H61 Specifications

General

Socket	LGA 1155
Memory Type	DDR3
PCI Express Version	2.0
RAID Support	No
Chipset	Intel H61
Memory Slots	2
Max Memory Supported	16 GB (depending on the manufacturer)
SATA Ports	4 x SATA 3Gb/s
USB Ports	10 (USB 2.0)
Form Factor	Micro-ATX
Integrated Graphics	Yes (requires CPU with integrated graphics)
Graphics Outputs	VGA, DVI, HDMI (depending on the manufacturer)
