Intel H61 User Manual

25
The optional settings: [Disabled]; [Enabled].
Use this item to enable or disable each SATA port.
 Intel(R) Rapid Start Technology
* ‘Intel(R) Rapid Start Technology’ is only optional for NLB75 Series, under the
condition that ‘SATA Mode Selection’ is set as [AHCI] mode.
Press [Enter] to go to next screen to enable or disable ‘Intel(R) Rapid Start
Technology’.
*When set as [Enabled], user can also make further settings in the following items
that appear:
Entry on S3 RTC Wake
Use this item to enable or disable RapidStart innovation upon S3 RTC wake.
Entry After
Use this item to enable RTC wake timer at S3 entry.
The optional settings are: [Immediately]; [1 minute]; [2 minutes]; [5 minutes];
[10 minutes]; [15 minutes]; [30 minutes]; [1 hour]; [2 hours].
Active Page Threshold Support
Use this item to enable or disable support for RST with small partition.
The optional settings are: [Disabled]; [Enabled].
*When set as [Enabled], user can also make further settings in the following items
that appear:
Active Memory Threshold
The optional settings: [Disabled]; [Enabled].
This item is for user to try to support RST when partition size is bigger than Active
Page Threshold size in MB. When set as zero, it will be in auto mode and check if
partition size is enough at S3 entry.
 PCH-FW Configuration
Press [Enter] to see ME information and make settings for Firmware Update
Configuration.
 Firmware Update Configuration
Press [Enter] to make settings for ME FW Image RE-Flash.
ME FW Image RE-Flash
Use this item to enable or disable ME FW Image Re-Flash function.
* In the case that user needs to update ME firmware, user should set ‘ME FW
Image Re-Flash’ as [Enabled], save the settings and exit. The system will turn off
and reboot after 4 seconds. If the user goes to BIOS screen again will find this item
is set again as [Disabled], but user can still re-flash to update firmware next time.
 USB Configuration
USB Configuration:
Legacy USB Support
The optional settings are: [Enabled]; [Disabled]; [Auto].
[Enabled]: To enable legacy USB support.
[Disabled]: to keep USB devices available only for EFI specification,
[Auto]: To disable legacy support if no USB devices are connected.
