Intel P35 User Manual

6
Jumpers
Jumper Name Description Page
JBAT CMOS RAM Clear 3-pin Block P.7
JP1 Keyboard Power On Enabled/Disabled 3-pin Block P.8
JP3 USB Power On Enabled/Disabled 3-pin Block P.8
JP4 USB Power On Enabled/Disabled 3-pin Block P.8
Connectors
Connector Name Description Page
ATXPWR24P ATX Power Connector 24-pin Block P.23
ATX12V ATX 12V Power Connector 4-pin Block P.24
J1 Large 4-PIN Power Connector 4-pin Block P.24
PS2KB/MS PS/2 Mouse & PS/2 Keyboard Connector 6-pin Female P.24
USB1 USB Port Connector 4-pin Connector P.24
US1(USB) USB2.0 Connnector USB Connector P.24
UL2 RJ45 LAN Port Over USB Conn. RJ-45, Connector P.24
AUDIO1 / SURROUND1 8-CH Audio Connector 6 phone jack Connector P.24
FDD Floppy Driver Connector 34-pin Block P.25
IDE1/IDE2 Primary/Secondary IDE Connector 40-pin Block P.25
SATA1~4 Serial ATA2 Connector 7-pin Connector P.26
US1 External Serial ATA2 Connector 7-pin Connector P.26
SPDIF in/ Out SPDIF In/Out coaxial Connectors Coaxial connectors P.29
COM1 Serial Port 9-pin Block P.29
Headers
Header Name Description Page
AUDIO SPEAKER, MIC header 9-pin Block P.27
USB2,
USB3,USB4,USB5
USB Port Headers 9-pin Block P.27
SPEAK PC Speaker connector 4-pin Block P.27
PWR LED Power LED 3-pin Block P.27
JW
_
FP
(PW LED/Reset/
IDE LED/PW Switch)
Front Panel Header
(including Power LED/ IDE activity
LED/Reset switch / Power On Button lead)
9-pin Block P.27
CPUFAN FAN Headers 4-pin Block P.28
SFAN1, SFAN2 FAN Headers 3-pin Block P.28
CDIN CD Audio-In Header 4-pin Block P.28
IR IR Header 5-pin Block P.29
Parallel Parallel Header 25-pin Block P.29
HDMI-SPDIF SPDIF header 2-pin Block P.29
Expansion Sockets
Socket/Slot Name Description Page
LGA 775 Socket CPU Socket LGA 775 CPU Socket
P.9
DIMM1~4 DDR2 Module Sockets 240-pin DDR2 Module Sockets
P.19
PCI1∼ PCI2
PCI Slot 32-bit PCI Local Bus Expansion slots
P.21
PE1 PCI-Express x16 Slot PCI-Express x16 Expansion Slot
P.21
PE4 PCI-Express x 16 Slot PCI-Express x4 Expansion Slot
P.21
PE2,PE3 PCI-Express x1 Slot PCI-E x 1 Bandwidth
P.21
