3-9 PnP/PCI Configuration Setup
This section describes configuring the PCI bus system. PCI, or Personal Computer
Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the
CPU itself uses when communicating with its own special components. This section covers
some very technical items and it is strongly recommended that only experienced users should
make any changes to the default settings.
Phoenix – AwardBIOS CMOS Setup Utility
PnP/PCI Configurations
Item Help
IRQ Resources Press Enter
PCI/VGA Palette Snoop Disabled
***PCI Express Relative Items ***
Maxim Payload Size 128
↑↓→←
Move Enter:Select Item +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Optimized Defaults F7:Standard Defaults
IRQ Resources
When resources are controlled manually, assign each system interrupt a type, depending on
the type of device using the interrupt.
PCI/VGA Palette Snoop
Leave this field at Disabled. The settings are Enabled, Disabled.
3-10 PC Health Status
This section shows the Status of you CPU, Fan, and Warning for overall system status. This
is only available if there is Hardware Monitor onboard.
Phoenix – AwardBIOS CMOS Setup Utility
PC Health Status
Item Help
Shutdown Temperature Disabled
Show PCHealth in POST Enabled
> Smart FAN Configurations Press Enter
VCC3v 3.31V
Vcore 1.28V
NB1.25V 1.26V
+5V 5.12V
+12V 11.88V
5VSB 5.00V
VDIMM 1.87V
3VSB 3.37V
Vbat 3.28V
CPU Temperature 64
°
C147
°
F
System Temperature 38
°
C/96
°
F
CPUFAN Speed 2912RPM
SFAN1 Speed 0 RPM
SFAN2 Speed 0 RPM
Menu Level >
↑↓→←
Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Optimized Defaults F7:Standard Defaults
Shutdown Temperature
This item can let users setting the Shutdown temperature, when CPU temperature over this
setting the system will auto shutdown to protect CPU.
Show PC Health in Post
During Enabled, it displays information list below. The choice is either Enabled or Disabled
Smart FAN Configurations
To Next Page
