Intel P35 User Manual

42
Please refer to section 3-10-1
Current CPU Temperature/Current System Temp/Current FAN1, FAN2 Speed/Vcore/
Vdd/3.3V/+5V/+12V/-12V/VBAT(V)/5VSB(V)
This will show the CPU/FAN/System voltage chart and FAN Speed.
3-10-1 Smart FAN Configurations
Phoenix – AwardBIOS CMOS Setup Utility
Smart FAN Configurations
Item Help
CPUFAN Smart Mode Enabled
CPU SmartFAN Full-Speed 50
CPU SmartFAN Idle Temp 30
Menu Level >
↑↓→←
Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Optimized Defaults F7:Standard Defaults
CPU/SFAN1 Smart FAN Full-Speed Temp
This item allows you setting the FAN works in full speed when the temperature over the value
which out set. If the temperature below the value but over the Idle Temperature, the FAN
will works over 60% of full speed, and the higher temperature will gain higher FAN speed,
after over the temperature which this item setting, the FAN works in full speed.
CPU/SFAN1 Smart FAN Idle Temp
This item allows you setting the FAN works in 60% of full speed, when the temperature
lower than the temperature which you setting.
3-11 Miscellaneous Control
This section is for setting CPU Miscellaneous Control.
Phoenix – AwardBIOS CMOS Setup Utility
Miscellaneous Control
Item Help
Auto Detect PCI Clk Enabled
Spread Spectrum Disabled
Clock ASYNC/SYN mode ASYNC Mode
Linear PCIEX Clock 100MHz
** Current Host/PCI Clock is 200/33MHZ
Host/PCI Clock at Next Boot 200/33MHZ
** Current DRAM CLOCK 667MHz **
DRAM Clock at Next Boot By SPD
CPU Vcore Select Defaulted(1.30625v)
CPU Vcore 7-Shift Normal
NB 1.25v Select 1.25v(Defaulte)
SB 1.5v Select 1.50v(Defaulte)
VDIMM Select 1.87V(Default)
FSB 1.2v Select 1.20v(Defaulte)
Menu Level >
↑↓→←
Move Enter:Select Item +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Optimized Defaults F7:Standard Defaults
CPU Clock Ratio
This item allows you to select the CPU ratio.
Auto Detect PCI/DIMM Clock
This item allows you to enable/disable auto detect PCI/DIMM Clock.
The settings are: Enabled, Disabled.
Spread Spectrum
This item allows you to set the Spread Spectrum.
