1-2 Specification
Spec Description
Design
∗ ATX form factor 4 layers PCB size: 30.5x23.5cm
Chipset
∗ Intel P35 Express Chipset
∗ Intel ICH9 chipset
CPU Socket
LGA775
∗ Support Intel Pentium 4, Celeron
（
FSB 800/1066/1333 MHZ）
,
Pentium D, Core 2 Duo and Core 2 Quad 775-Land LGA
Package utilizes Flip-Chip Land Grid Array (FCLGA) package
processor
∗ Support FSB Frequency 800 / 1066/1333MHz
Memory Socket
∗ 240-pin DDR2 Module socket x 4
∗ Support 4 pcs DDR2 667 /DDR2 800MHz DDR2 Modules
Expandable to 8.0GB
∗ Support Dual channel functions
Expansion Slot
∗ PCI-Express x16 slot 2pcs ; the two PCI-E x16 slots in same
color support the AMD CrossFire Technology with 2GB/s
concurrent bandwidth in 16 lane + 4 lane Mode;
∗ PCI-Express x1 slot 2pcs delivers up to 512MB/s concurrent
bandwidth
∗ 32-bit PCI slot x 2pcs
Integrate IDE and
Serial ATA2 RAID
∗ The Intel ICH9 supports four Serial ATA ports provide 3.0 Gb
/sec data transfer rate.
∗ JMB363 Serial ATA RAID PCI controller that supports PCI
Bus Mastering, ATA PIO/DMA and the ULTRA DMA 66 / 100
/ 133 functions that deliver the data transfer rate up to 133 MB/s
for 2 IDE Devices; two Serial ATA ports provide 3.0 Gb /sec
data transfer rate for two serial ATA devices
Gigabit LAN
∗ Integrated Realtek RTL8111B-VC-GR PCI-Express Gigabit
LAN function.
∗ Supports Fast Ethernet LAN function provide 10Mb/100Mb/
1Gb /s data transfer rate
8CH-Audio
∗ Realtek ALC888 Azalia 8-channel Audio Codec integrated
∗ Support 8-channel 3D surround & Positioning Audio
∗ Audio driver and utility included
BIOS
∗ Award 8MB SPI Flash ROM
Multi I/O
∗ PS/2 keyboard and PS/2 mouse connectors
∗ Floppy disk drive connector x1
∗ ESATAx1 (Optional)
∗ Serial Port x1 / Parallel header x1
∗ Coaxial In/Out connector x1
∗ HDMI-SPDIF header x1
∗ IR connecter with 5-pin block x1
∗ USB2.0 port x 4 and headers x4 (connecting cable option)
∗ Audio connector (Line-in, Line-out, MIC/ 8CH Audio)

Intel P35 Specifications

General

Brand	Intel
Model	P35
Category	Motherboard
Language	English
