10 Intel® RAID Controller RS2BL080 Hardware User’s Guide
Figure 3. Connecting Cables between the RAID Controller and
Drives/Backplane
6. Install the server system cover and connect the power cords. For instructions, see
your server system documentation.
C
Ports 0-3
Ports 4-7
A
B
AF003197
