14 Intel® RAID Controller RS2BL080 Hardware User’s Guide
Technical Specifications
Table 2. Technical Specifications
JT12 Individual Drive Fault LED
header
8 x 2 header Indicates drive faults. There is one LED per port.
When lit, each LED indicates the corresponding
drive has failed or is in the Unconfigured-Bad state.
The LEDs function in a direct-attach configuration
(there are no SAS expanders). Direct attach is
defined as a maximum of one drive connected
directly to each port.
Note: This header is used for RAID controllers
with internal SAS ports only.
JT13 Universal Asynchronous
Receiver/Transmitter (UART)
4-pin connector For factory and debug use
Jumper Description Type Comments
Specification Intel
®
RAID Controller RS2BL080
RAID-on-Chip (ROC ) LSISAS2108 Integrated ROC, 800 MHz
Operating voltage +3.3 V, +12 V
Card size Low profile, extended half-length (6.6-inch, MD2)
Array interface to host PCI Express* Revision 2.0, x8 lane width 5.0 Gbps
SAS/SATA bus speed Up to 6 Gbps per port, point-to-point
SAS/SATA ports 2x4 internal ports, 32 devices per port with expanders
Physical and virtual drive
support
32 physical drives, 64 virtual drives, and 16 RAID arrays per
controller
Cache 512 MB DDR2 800 MHz SDRAM, optional battery backup
Firmware 8 MB in reflashable flash ROM
Compatible devices • 2.5-inch and 3.5-inch SAS or SATA II drives
• Non disk devices including expanders
• Can support drives of mixed capacity
Cabling • Small, thin cables that do not restrict airflow
• Shared connectors for multiple drives
Redundant configuration 32 KB NVRAM and config-on-disk (COD)
Enclosure management • SGPIO
• In-band and out-of-band SES
Enclosure support Assumes one SEP per enclosure
