Intel® RAID Controller RS2BL080 Hardware User’s Guide 17
Electrical Characteristics
Table 5. Electrical Characteristics
Safety Characteristics
The Intel
®
RAID Controller RS2BL080 meets or exceeds the requirements of UL
flammability rating 94 V0. Each bare board is marked with the supplier name or
trademark, type, and UL flammability rating. For the boards installed in a PCI bus slot, all
voltages are lower than the SELV 42.4 V limit.
Characteristic Values
PCI +12 V 1.0A-1.81A
PCI +3.3 Aux 30 mA
PCI +3.3 V 330 mA
Temperature
Non-operating
Operating
-30°C to +80°C without the optional battery /
0°C to 45°C with the optional battery
0°C to 60°C without the optional battery /
0°C to 40°C with the optional battery
Relative Humidity
Operating 5%-90% non-condensing ( 20%-80% non-condensing for the RAID
controllers)
Airflow > 200 linear feet per minute (LFPM)
