Intel® Server S1200SP Family Configuration Guide
5
1.2 Intel® Server Board S1200SP Product Family Overview
The server board product family consists of three server board models: S1200SPL, S1200SPS and S1200SPO.
Figure 2. Intel® Server Board S1200SP product family
The following table provides an overview of available server board options for the Intel® Server Board S1200SP product family. Each line item
identifies key features of the specified server board. Order code information and full product descriptions for each option are provided in later
sections.
S1200SPL
S1200SPS
S1200SPO
Board Form Factor
uATX (9.6” x 9.6”)
uATX (9.6” x 9.6”)
uATX (9.6” x 9.6”)
Procesor Support
Intel® Xeon® processor E3-1200 v5 series
Intel® Core®processor i3 series
Intel® Xeon® processor E3-1200 v5 series
without HD Graphic
Intel® Xeon® processor E3-1200 v5 series
without HD Graphic
Intel® Chipset
C236
C232
C236
DIMM Slots
4
4
4
DIMM Type
DDR4 UDIMM
DDR4 UDIMM
DDR4 UDIMM
PCIe 3.0 Add-in Card Support
1 – PCIe 3.0 x8 elec, x16 mech
1 – PCIe 3.0 x4 elec, x8 mech
1 – PCIe 3.0 x8 elec, x8 mech
1 – PCIe 3.0 x8 elec, x16 mech
1 – PCIe 3.0 x4 elec, x8 mech
1 – PCIe 3.0 x8 elec, x8 mech
1 – PCIe 3.0 x8 elec, x16 mech with Riser
Card support
Riser Card Support
No
No
Yes
Intel® Integrated SAS RAID Module
Support
Yes
No
Yes
Intel® I/O Module Support
No
No
Yes
On-Board Storage Options
8 – 6Gb SATA Ports
1 – M2 SATA Connector
6 – 6Gb SATA Ports
8 – 6Gb SATA Ports
1 – M2 SATA Connector
On-Board Network Connectivity
Dual Intel® i210 Gigabit Ethernet
Dual Intel® i210 Gigabit Ethernet
Dual Intel® i210 Gigabit Ethernet
Intel® Server Board S1200SPL
Intel® Server Board S1200SPS
Intel® Server Board S1200SPO
