Intel S1200SP User Manual

Intel® Server S1200SP Family Configuration Guide
35
Intel Product Code
Order Information
Product Description
Product Type
iPC - FUP4X35NHDK
Demo only
MM# - 912770
UPC - 00735858219488
EAN - 5032037016247
MOQ - 4
Fixed Drive Carrier for Fixed Pedestal Chassis
 Pedestal Spare FRU
iPC - FUPSESK
Demo only
MM# - 912774
UPC - 00735858219525
EAN - 5032037016285
MOQ - 1
Chassis Maintenance Kit for P4000S Chassis (Electrical Spare
Kit)
• These parts in the kit can be used with S1200SP:
• 1x intrusion cable, 200mm
• 3x SATA power cables, one 4- pin ATX power header to 2
SATA power headers, 150mm
• 1x SATA Cable, one right angle header to one vertical
header, 600mm (4 cables)
• 1xSGPIO Cable, one 5-pin header to one 5-pin header and
one 4-pin header
• 1x I
2
C Cable, one 5-pin header to one 3 pin header, 600mm
• These parts in the kit cannot be used with S1200SP:
• 1x Front Panel Cable, 920mm
• 1x USB Cable, one 2x5 pin header to two USB type A female
headers, 950mm, USB 2.0 cable
• 1xSATA power adaptor extend cable, 24-pin header to 24-
pin header, 630mm
 Pedestal Spare FRU
iPC - FUPSNHFANE3
Demo only
MM# - 912772
UPC - 00735858219501
EAN - 5032037016308
MOQ - 1
92mm Rear Fan Kit
Includes:
(1) 92 mm fan
(1) rear vent cover
Spare for P4000 Pedestal* Chassis
 Pedestal Spare FRU
iPC - AS1200SPSIOS
Demo only
MM# - 944200
UPC - 00735858306591
EAN - 5032037080057
MOQ - 10
I/O Shield for Intel® Server Board S1200SPS
 Pedestal Spare FRU

Intel S1200SP Specifications

General

PCI Express Revision	3.0
Instruction Set	64-bit
Network	Dual Gigabit Ethernet
Number of Threads	Varies by CPU
Bus Speed	Varies by CPU
TDP	Varies by CPU
Instruction Set Extensions	Intel® SSE4.2
Thermal Solution Specification	Varies by CPU
