Miscellaneous Events
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
108 Intel order number G90620-002 Revision 1.1
11.8 Add-In Module Presence Sensor
Some server boards provide dedicated slots for add-in modules/boards (for example, SAS, IO, and PCIe-riser). For these boards the
BMC provides an individual presence sensor to indicate whether the module/board is installed.
Table 85: Add-In Module Presence Sensor Typical Characteristics
Byte
Field
Description
11
Sensor Type
15h = Module/Board
12
Sensor Number
0Eh = IO Module Presence
0Fh = SAS Module Presence
13h = IO Module2 Presence
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 08h (“digital” discrete)
14
Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset
0h = Device Removed/Device Absent.
1h = Device Inserted/Device Present
15
Event Data 2
Not used
16
Event Data 3
Not used
11.8.1 Add-In Module Presence – Next Steps
If an unexpected device is removed or inserted, ensure that the module has been seated properly.
