Intel S2600GL

System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
Linux* Kernel Panic Records
Revision 1.1 Intel order number G90620-002 131
Table 106: Linux* Kernel Panic String Extended Record Characteristics
Byte
Field
Description
1
2
Record ID
ID used for SEL Record access
3
Record Type
[7:0] – F0h = OEM non-timestamped, bytes 4-16 OEM defined
4
Slave Address
The slave address of the card saving the panic
5
Sequence
Number
A sequence number (starting at zero)
6
…
16
Kernel Panic Data
These hold the panic sting. If the panic string is longer than 11 bytes, multiple messages will be sent with increasing sequence
numbers.
