System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
Processor Subsystem
Revision 1.1 Intel order number G90620-002 69
Table 57: Processor MSID Mismatch Sensor Typical Characteristics
Byte
Field
Description
11
Sensor Type
07h = Processor
12
Sensor Number
81h = Processor 1 MSID Mismatch
87h = Processor 2 MSID Mismatch
88h = Processor 3 MSID Mismatch
89h = Processor 4 MSID Mismatch
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 03h (“digital” discrete)
14
Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset = 1h (State Asserted)
15
Event Data 2
Not used
16
Event Data 3
Not used
6.6.1 Processor MSID Mismatch Sensor – Next Steps
Verify the processor is supported by your baseboard. Check your boards Technical Product Specification (TPS).
