Sensor Cross Reference List
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
20 Intel order number G90620-002 Revision 1.1
Sensor
Number
Sensor Name
Details Section
Next Steps
A5h
Power Supply 2 Fan Tachometer 2
(PS2 Fan Tach 2)
Power Supply Fan Tachometer
Sensors
Power Supply Fan Tachometer Sensors – Next Steps
A6h
Intel
®
Xeon Phi
™
Coprocessor
Status 3
(MIC 3 Status)
Intel
®
Xeon Phi
™
Coprocessor
(MIC) Status Sensors
Intel
®
Xeon Phi
™
Coprocessor (MIC) Status Sensors Next Steps
A7h
Intel
®
Xeon Phi
™
Coprocessor
Status 4
(MIC 4 Status)
Intel
®
Xeon Phi
™
Coprocessor
(MIC) Status Sensors
Intel
®
Xeon Phi
™
Coprocessor (MIC) Status Sensors Next Steps
B0h
Processor 1 DIMM Aggregate
Thermal Margin 1
(P1 DIMM Thrm Mrgn1)
Thermal Margin Sensors
Table 40: Thermal Margin Sensors – Next Steps
B1h
Processor 1 DIMM Aggregate
Thermal Margin 2
(P1 DIMM Thrm Mrgn2)
Thermal Margin Sensors
Table 40: Thermal Margin Sensors – Next Steps
B2h
Processor 2 DIMM Aggregate
Thermal Margin 1
(P2 DIMM Thrm Mrgn1)
Thermal Margin Sensors
Table 40: Thermal Margin Sensors – Next Steps
B3h
Processor 2 DIMM Aggregate
Thermal Margin 2
(P2 DIMM Thrm Mrgn2)
Thermal Margin Sensors
Table 40: Thermal Margin Sensors – Next Steps
B4h
Processor 3 DIMM Aggregate
Thermal Margin 1
(P3 DIMM Thrm Mrgn1)
Thermal Margin Sensors
Table 40: Thermal Margin Sensors – Next Steps
B5h
Processor 3 DIMM Aggregate
Thermal Margin 2
(P3 DIMM Thrm Mrgn2)
Thermal Margin Sensors
Table 40: Thermal Margin Sensors – Next Steps
B6h
Processor 4 DIMM Aggregate
Thermal Margin 1
(P4 DIMM Thrm Mrgn1)
Thermal Margin Sensors
Table 40: Thermal Margin Sensors – Next Steps
