INTELECT LEGEND STIM USER MANUAL
9
Adverse Effects
• Skin irritation and burns beneath the electrodes have been reported with the use of therapeutic electrical stimulation.
HAND HELD PROBE (Optional)
HIGH VOLT Probe
The High Volt probe is used to deliver stimulation manually. Select the High Volt waveform then simply plug the Black lead
wire into the connector of the Probe. The Red lead wire from the same channel should be attached to an electrode and
placed near the treatment site. The default polarity for High Volt is positive. When using this setting, the Red lead is
positive and the Black lead is negative.
• Select the parameters you wish to change then press the start button to begin treatment.
Note: Place the ground electrode as close to the treatment site as possible
where it will not interfere with placement of
the active electrode; for example,
do not place the ground electrode on the leg if you are treating the arm.
User Maintenance
To clean, turn unit off and unplug the power supply. Clean the unit with a damp cloth. Do not use abrasive cleaners. A
small amount of mild household detergent may be used, if desired.
Between patient uses, patient applied parts should be wiped clean with a clean damp cloth, then use another clean cloth
to clean with a hospital grade germicide. Follow germicide manufacturer directions. Some highly concentrated germicide
mixtures could damage the product if not diluted in accordance with directions of the germicide manufacturer.
