INTELECT LEGEND STIM USER MANUAL
10
Technical Maintenance
No attempt should be made to disassemble the unit. Maintenance and all repairs should be made by authorized
personnel only. The manufacturer will not be held responsible for the results of maintenance or repairs by
unauthorized persons.
To fully maintain compliance with Federal Regulation Title 21 (21 CFR), this unit must be recalibrated annually. It is
recommended that all Chattanooga Group ultrasound products be returned to the factory or an authorized servicing
dealer for repairs or recalibration. It is also recommended after the replacement or repair of any major component.
The following items should be checked at least monthly to ensure proper operation of this unit:
1. Power cord and plug: Check to make sure the cord is not frayed, kinked or does not have torn or cut insulation.
2. Lead Wires: Check that the cables are not frayed, kinked or do not have torn or cut insulation.
Unit Orientation
Operator Interface – (Pages 12-13)
On the 2S: The operator interface consists of a Liquid Crystal Display (LCD)
On the 4S: The operator interface consists of a Liquid Crystal Display (LCD) and three Light Emitting Diodes (LEDs). The
operator is able to view Channel designation, Treatment time and Output on the LEDs and Parameter options on the LCD.
The software control of the Legend Stim has been designed to be extremely user friendly. First press the treatment mode
button of your choice, increase intensity and press start. The software also allows great flexibility should you desire to
change parameters.
