CONNECTING THE STIMULATOR
5.2 Connect electrodes to lead wires:
Insert the lead wire connector into electrodes connector (standard 0.08 inch female connection). MAKE SURE
THAT NO BARE METAL OF THE PINS IS EXPOSED.
Caution:
* Always use the electrodes with the requirements of the EN60601-1
and EN60601-2, such as with CE mark, or are legally marketed in
US under 510(K) procedure.
NOTE: Always read this instruction manual before use.
PREPARATION FOR USE
5.1 Check Battery:
Insert a fresh 9V alkaline or rechargeable battery into the battery compartment. Make sure you are installing the
battery properly. The battery is inserted in the casing on the back of the stimulator unit. BE SURE TO MATCH
THE POSITIVE AND NEGATIVE ENDS OF THE BATTERY TO THE MARKINGS IN THE BATTERY
COMPARTMENT OF UNIT. To remove the battery cover, press and pull down following the direction of the
arrow indicated on the battery cover.
5. INSTRUCTIONS FOR FOR USE
109
