5.4 Place electrodes on skin:
Apply electrodes to the exact site indicated by your prescribing
practitioner, following the instruction included with the electrodes labeling.
Before applying electrodes, be sure the skin surface over which electrodes
are placed is thoroughly cleaned and dried. Make sure the electrodes are
placed firmly to the skin and make good contact between the skin and the
electrodes. Place the electrodes over the skin; attach them properly,
firmly, and evenly.
ADJUSTING THE CONTROLS
5.5 Adjust Output:
Turn Amplitude Control knob for Channel 1 or 2 clockwise. You will hear
a " beep" sound. Before you increase the Amplitude, you must select the
mode, Ramp, ON Time, OFF Time, Rate and Width.
5.3 Connect lead wires to unit:
Before proceeding to this step, be sure the unit is completely turned OFF. Holding the insulated portion of the lead
wire connector, insert the angled-"L" plug into the receptacle on the top of the main unit. Ensure the leads are
inserted correctly.
The unit has two output receptacles controlled by Channel 1 and Channel 2 Amplitude Control knobs at the top of
the unit. You may choose to use one channel with one pair of lead wires or both channels with two pairs of lead
wires. Using both channels give the user the advantage of stimulating two different areas at the same time.
1211
Self-adhesive
Electrodes Pads
Angle"L"-shape
plug
To Next Page
