Channel Dual channels, isolated between channels
Pulse Amplitude 0 ~ 80 mA = 0 ~ 40 volts, adjustable (at 500 ohm load)
Pulse Frequency (Hz) 2 ~ 150
Pulse Width (µs) 60 ~ 250
Waveform Asymmetric biphasic square pulse.
Timer Control (mins) 30, 60, or Constant
Power Supply 9V DC square shape battery
Size (D x W x H) 1.0" x 2.4" x 3.6" (26 mm x 62 mm x 91 mm)
Weight (including battery) 4.4 oz (126 g)
Safety standard EN 60601-1, EN 60601-1-2, IEC 60601-2-10
Operation Ambient Temperature Range 50 ~ 95ºF (10 ~ 35ºC)
Operation Ambient Humidity Range 20 ~ 90% RH
Storage & Transportation Temperature Range 32 ~ 158º F (0 ~ 70ºC)
Storage & Transportation Humidity Range 20 ~ 90% RH
All values have ±10% tolerance.
16
15
6. SPECIFICATION
5. HANDLING AND STORAGE
Keep this device in the carrying case and store it at room temperature.
Stimulation Modes descriptions
Mode BURST NORMAL Modulation
Frequency 2~150Hz 2~150Hz, 2~150Hz
Pulse Width 60~250µs 60~250µs 60~250µs
Cycle Time 0.5 Sec. Constant. 4 Secs.
Loading: 500Ω
*All values have±10% tolerance.
7 ACCESSORIES
Self-Adhesive Electrodes 4 PCS.
9 V Battery 1 PC.
Lead Wires 2 PCS.
Instruction Manual 1 PC.
