5.2 Doorbell B lock connection
GS
INDOOR
GND
NO
NC
COM
12V OUT
+
-
GS
INDOOR
GND
NO
NC
COM
12V OUT
+
-
GS
INDOOR
GND
NO
NC
COM
12V OUT
+
-
GS
INDOOR
GND
NO
NC
COM
12V OUT
Note 1
Note 2
Note 2
Note 2
Electric lock
Electric lock
Magnetic lock
Electric lock
Electric lock
Note 2
Note 2
Note 1: Short COM and 12V OUT if lock doesn't have it's own power supply.
Note 2: Reverse diode not used only for electric gate system.
Must be connected for all other locks.
-13-
