Intense UZZI - Installing Rear Derailleur Hanger

12 // uzzi user Manual
INSTALLING REAR DERAILLEUR HANGER //
A Grease outer edges of derailleur hanger (#130790) and insert from the back of
the dropout. Insert mounting bolt from the front and torque to 11 NM / 100 in-lbs
(image #23 & 24).
22
INSTALLING ADJUSTER CONES (CON'T) //
C Install trim caps (#140004) into drive-side pivot bolts (IMAGE #22).
23
24
